Galvanized Steel Sheet Light Steel Trusses Roll Forming Machine For Villa House Frame

Categories: Light steel roll forming machine

The roof panel roll forming machine is of great significance in the construction industry.

Firstly, it is mainly used for manufacturing various types of villa house frames. It is an automated device used to shape light gauge steel into structural profiles such as studs, tracks, joists, and trusses. It forms steel coils through a series of rollers, with integrated punching and cutting systems for precision manufacturing. Commonly used in prefabricated construction and modular buildings, it enables fast, accurate, and efficient production of lightweight steel framing components.

Chat Now

Product Details

Features:

Light steel roll forming machine adopts welded steel frame structure, it make sure metal sheet machine can operation more stably.

AC frequency conversion motor reducer drive, chain transmission, roller surfaces polishing, hard plating, heat treatment and chrome coating.

It will work fully automated with PLC (Programmable Logic Controller) control for efficient, unattended operation.

It Can produce 10–25 meters per minute or more, depending on the material thickness and profiles.

Technical Parameters:

item	value
Showroom Location	Botou, Cangzhou
Condition	New
Type	roll forming machine
Tile Type	Colored Steel
Use	ROOF
Production Capacity	8-15m/min
Place of Origin	Hebei,China
Brand Name	Shitong
Voltage	380V 220v 415v 440v 480v
Dimension(LWH)	4200mm1000mm1400mm
Weight	2500kg
Warranty	1 Year
Key Selling Points	Easy to Operate
Rolling thinckness	0.3-0.8mm
Feeding width	300mm
Machinery Test Report	Provided
Video outgoing-inspection	Provided
Marketing Type	New Product 2024
Warranty of core components	1 Year
Core Components	Motor, Bearing, Gear, Pump, Engine, PLC
Raw material	PPGI PPGL GI GL
Roller material	High Grade 45# Steel
Cutting blade material	Cr 12 High Grade Steel
Cutting type	Automatic Hydraulic Cutting
Shaft material	45# Steel Outer Diameter: 70mm
Roller stations	15 Stations

Applications:

Product Application Occasions and Scenarios for SHITONG Roofing Sheet Roll Forming Machine:

The SHITONG roofing sheet roll forming machine is a versatile and efficient equipment designed for the production of metal roofing and wall panels. With its advanced features and sturdy construction, this machine is suitable for various application occasions and scenarios:

Residential Buildings: The roofing sheet roll forming machine can be used to manufacture high-quality metal roofing sheets for residential properties, ensuring durability and aesthetic appeal.
Commercial Structures: This machine is ideal for producing roofing and wall panels for commercial buildings such as warehouses, factories, and shopping centers.
Industrial Facilities: The model is well-suited for industrial applications where robust and weather-resistant roofing materials are required.
Agricultural Buildings: Farmers and agricultural businesses can benefit from using this machine to create durable roofing sheets for barns, storage sheds, and other agricultural structures.
Construction Projects: Contractors and builders can utilize the roofing sheet roll forming machine to produce custom metal roofing and wall panels for a wide range of construction projects.

With its CE certification and reliable performance, the SHITONG roofing sheet roll forming machine is a preferred choice for customers in need of high-quality metal sheet roll forming equipment. The machine’s cutter material, Cr12MoV, and side panel thickness of 20mm ensure precision and durability in the production process.

Customers can place orders for this machine with a minimum quantity of 1 set and expect delivery within 50 days. The packaging details include plastic film for safe transportation. Payment terms are by T/T, and the supply ability is 10 sets per month. Weighing 4.5T, this machine is equipped with PLC control for easy operation and efficient output.

Support and Services:

The Light Steel Roll Forming Machine product offers comprehensive Product Technical Support and Services to ensure optimal performance and customer satisfaction. Our technical support team is dedicated to assisting customers with installation, operation, and troubleshooting of the machine. Additionally, we provide training programs to educate users on the proper usage and maintenance of the equipment. Our service team is available to address any inquiries or issues that may arise, offering prompt and reliable assistance to maximize the efficiency and longevity of the Light steel Roll Forming Machine.

Packing and transportation

Product Packaging:

The Roll Forming Machine will be carefully packaged to ensure safe delivery. It will be securely wrapped and placed in a sturdy wooden crate to prevent any damage during transit. Additionally, all delicate components will be protected with padding and bubble wrap.

Shipping Information:

Once the Roll Forming Machine is packaged and ready for shipment, it will be transported by a reliable shipping carrier. You will be provided with a tracking number so you can monitor the delivery progress. The estimated delivery time will depend on your location and chosen shipping method.
